CHW Plant Builder Commercial License

Commercial activation license for the CHW Plant Graphic Builder — a standalone design tool for the Tridium Niagara framework that lets you configure any chilled water plant, preview it as a live animated graphic, and export it as a native Niagara PX page with its full photoreal component pack. Draw the plant in your browser in minutes; drop the export into Workbench, bind your points and you're commissioning — not drawing.

What the builder does

• Build the plant - start from plant presets including primary-only, primary/secondary with decoupler, variable primary and waterside economizer arrangements, or configure a custom plant: chillers, chilled and condenser water pumps, cooling towers, headers, isolation and bypass valves, plate heat exchangers and makeup, drawn to your plant's flow direction.
• Photoreal, animated components - pumps and tower fans spin, valves stroke and flow paths respond to preview values in the bound graphic preview, so you see exactly how the finished graphic will behave on your station before you export.
• Draggable live point callouts - point bezels for chilled water supply and return temperatures, delta T, flow, differential pressure, condenser water temperatures, tower approach, chiller status, load and kW/ton, pump status and speed; drag each callout anywhere on the graphic to match your site's documentation style.
• Inspect components - step through every component in the plant, review its animation states and confirm the graphic before binding.
• Bind ORDs and export - enter your Niagara ORD paths per point, then export a native PX page that displays the actual plant graphic with live Niagara overlays bound to your station's points.
• Summary and sequence - a top-to-bottom workflow that saves as you go, with a final summary of the plant configuration and point map.

Built for Niagara, not just for browsers

• Exports native .px pages plus the complete component pack — draggable, point-bound and ready for Workbench.
• No third-party graphics runtime and no extra licensing on the station.
• Photoreal SVG equipment assets that scale cleanly on control room displays, desktop and tablet.
• Consistent component naming so repeat plants across a portfolio stay uniform.

How the license works

• One-time commercial license — activates the builder for one installation, no annual renewal.
• 25 CHW Component Pack export credits included. Each PX export consumes one credit; building, configuring and previewing are always free.
• Top up 25, 50 or 100 export credits anytime — select CHW Plant Builder and your pack size on the refill page, or buy from the My CHW License portal. The builder itself keeps working either way.
• Your license key is issued instantly after successful payment, with activation instructions.

In the download

License key and activation guide. Every export delivers the native .px page and its component pack files, ready to import into your station. Free builder updates for the life of the license.
